AR400 BK
• Feature 52-piece high-density heatsink fin array to increase thermal surface.
• Four high conductive anti-gravity heat pipes allow for stable cooling efficiency.
• The base adopts direct-touch design for improved thermal conductivity.
• High airflow design fan provides outstanding airflow for thermal dissipation.
• Offset tower structure to ensure full-level RAM compatibility.
• Easy installation on Intel and AMD mainstream platforms.
Overview
Gallery
Specifications
| Model | AR400 BK |
| Socket compatibility(Intel) | Intel LGA1851/1700/1200/115X |
| Socket compatibility(AMD) | AMD AM5/AM4 |
| Product dimensions | 120x71x155mm |
| Heatsink dimensions | 120x45x155mm |
| Heatpipes | Φ6mmx4 |
| Bearing Type | Hydraulic Bearing |
| Number of fans | 1 |
| Fan Dimensions | 120x120x25mm |
| Fan Speed | 800~1800RPM±10% |
| Fan Airflow | 73.5CFM |
| Fan Air Pressure | 2.2mmH2O |
| Fan Noise | ≤31.6dB(A) |
| Fan Connector | 4-pin PWM |
| Fan Rated Voltage | 12 VDC |
| Fan Rated Current | 0.21A±10% |
| Fan Power Consumption | 2.52 W |
| LED Type | / |
| LED Connector | / |
| LED Rated Voltage | / |
| Net Weight | 503g |
