AK600
·Features a 140x79mm large-area fin with micro-convex turbulence surface technology, delivering more stable cooling performance.
·Equipped with a brand-new 140mm high-performance and low-noise ring-blade fan.
·Direct-touch Heatpipe base delivers optimized thermal transfer performance.
·Adopts a quick-access installation design with precision positioning cut-out for convenient bracket assembly.
·Offset tower design for easier installation and improved RAM clearance.
Overview


Gallery



Specifications
| Model | AK600 |
| Socket compatibility(Intel) | Intel LGA1851/1700/1200/115X |
| Socket compatibility(AMD) | AMD AM5/AM4 |
| Product dimensions | 140x105x159mm(LxWxH) |
| Heatsink dimensions | 140x79x159mm(LxWxH) |
| Heatpipes | Φ6mmx6 |
| Bearing Type | Hydraulic Bearing |
| Number of fans | 1 |
| Fan Dimensions | 140x140x25mm(LxWxH) |
| Fan Speed | 500~1500RPM±10% |
| Fan Airflow77.68 | 68.3CFM |
| Fan Air Pressure | 2.4mmH2O |
| Fan Noise | ≤ 23.31dB(A) |
| Fan Connector | 4-pin PWM |
| Fan Rated Voltage | 12 VDC |
| Fan Rated Current | 0.25A±10% |
| Fan Power Consumption | 3W |
